2.11 The set value for leaving the factory
2.11.1 The set value of the automatic adjuster of the voltage AVR
Output voltage is set as rated voltage; the setting of units load protecting current
is the 110% of the rated load.
(The following table is the reference value, the electric parts for AVR will be
changed according to the temperature)
60HZ 120/240V Units
Model
Rated
power
(KVA)
Rated
current
(A)
Rated
voltage
(V)
Max
power
(KVA)
Max
current
(A)
Current
protected
value (A)
KDE2200E
KDE3500E
KDE6500E
KDE6700TA
KDE6500E3
Frequency
(Hz)
60
60
60
60
60
1.7
3
4.5
4.5
5
7.0
12.5
18.8
18.8
6.9
2
3.3
5.0
5.0
5.5
120/240
120/240
120/240
120/240
416/240
8.3
13.8
20.8
20.8
7.6
14
21.5-22.0
21.2
8
No protecting setting
Note: The setting of no function and model units leave the factory as the same model setting
in the above table
50HZ 230V Units
Model
Rated
power
(KVA)
Rated
current
(A)
Rated
voltage
(V)
Max
power
(KVA)
Max
current
(A)
Current
protected
value (A)
KDE2200E
KDE3500E
KDE6500E
KDE6700TA
KDE6500E3
Frequency
(Hz)
50
50
50
50
50
1.7
2.8
4.2
4.2
5
7.4
12.2
18.3
18.3
7.2
230
230
230
230
400/230
2
3
4.5
4.5
5.2
8.7
13
19.6
19.6
7.5
13.5
21
21
8
No protecting setting
Note: The setting of no function and model units leave the factory as the same model setting
in the above table
2.11.2 The protecting setting values of the digital panel divide to:
A The standard setting value of leaving factory
Low oil pressure protection: Protection by stopping if the oil pressure low for 5s,
display P-01:
Over frequency protection: Output frequency =55 65 HZ protection by
stopping for 5s, display P-02
Over voltage protection: The rated output voltage is 110%V, protection by
stopping for 3s, display P-03
Over load protection: The rated output current is 110%, protection by stopping for
1 hour ,display P-04
Charging malfunction warning: No protection, only display while charging
malfunction, display P-05.
B 5KW the special requirement of the North America:
Low oil pressure protection: Protection by stopping if the oil pressure low for 5s,
display P-01:
Lack frequency protection: Output frequency =57HZ protection by stopping for
20s, display P-02
Over frequency protection: Output frequency =65HZ protection by stopping for
3s, display P-02
Lack voltage protection: The output voltage is =105V or =210V, protection by
stopping for 20s, display P-03
Over voltage protection: The output voltage is =132V or =264V, protection by
stopping for 3s, display P-03
Over load protection: The output current is between 19.2A and 21.2A, protection
by stopping for 1 hour ,display P-04
Over load protection: The output current is =21.2A, protection by stopping for 20s
,display P-04
Charging malfunction warning: No protection, only display while charging
malfunction, display P-05.
