Kirisun T60 Service Manual

SN
Material NO
Specifications
QTY
14
7MHS-4072-08A-W
STP knob circlip
2
15
7MHC-4072-01A-W
STP knob nut
2
16
4SS7-3653-008-100
Speaker
1
17
7GCM-411-294-J
Sponge pad for FP560 LCD
1
18
6MD7-F04932-C
LCD module (for model T60)
1
19
7MHS-4245-02B-W
LCD hardware holder (for model T60)
1
20
7STF-019047B-SZHT-X
M1.9*4.7 thick-head self-tapping Phillips screw
2
21
7SMF-020040M-SZYB-N
R M2*4 cross recessed mushroom-head machine screw
(558/PT4200)
7
22
7MHR-4072-05A-W0
O-RING, material: silicone rubber, outer diameter 8mm,
wire diameter 1.5mm
2
23
6SS2-4345-HMC
4G main board PCBA suite (for model T60)
1
24
7SMF-020037M-SZCT-N
M2.0*3.7 cross recessed countersunk-head machine
screw AP570/DP570/T3500S
2
25
7MHS-4207-03A-W
PTT metal dome array (for model DP586)
1
26
7GCM-120070030-J
IPEX anti-drop sponge (for model T65)
3
27
6PD7-4232-HPA
PTT board (for model T60)
1
28
7NRC-4078-01A-N
Antenna connector nut (for model TP660)
1
29
7MHR-4207-06A-W0
O-shape ring of antenna (for model DP586), outer
diameter 11mm, wire diameter 1.5mm
1
30
3CR7-SMA-50JF-9
RF coaxial connector, cable, IPEX4 plug
1
31
7MHP-4207-03A-W0
DP586 top cover
1
32
7GCB-070001
Dustproof cloth for speaker, φ7
1
33
7SMF-014040M-SZYB-N
M1.4*4 cross recessed mushroom-head machine screw
2
34
6SS3-DC4252-C
KB-T65 battery, no logo
1
35
6SS3-BJ4038-B
KBJ-17 belt clip
1
36
7SMF-025080M-SZYB-Z
M2.5*8 cross round-and-mushroom headed machine
2

Kirisun T60 Specifications

General

Brand	Kirisun
Model	T60
Category	Two-Way Radio
Language	English
