Kirisun T60 Service Manual

SN
Material NO
Specifications
QTY
screw
37
7MHR-4207-01A-W3
Waterproof ring (for model DP586)
1
38
7MJS-4142-02A-W0
F9 PTT key spindle (limited)
1
39
7MHR-4232-01A-W3
SIM card silicon cover (for model T65)
1
40
7MHR-4182-01A-W0
Discharge waterproof pad (for model DP990)
1
41
7MHP-4232-01A-W0
Waterproof pad for earphone jack (for model T65)
1
42
7MHR-4072-06A-W0
O-RING, silicon rubber, outer diameter 4mm, wire
diameter 1.0mm
2
43
7SMS-025075M-SZYBN1
M2.5*7.5 torx round-head machine screw
2
44
7MHL-4232-01B-W
Aluminum housing (for model T65)
1
45
3WF7-05030-500C4
FPC cable
1
46
7GCM-020015010
Sponge mat (for model DP990)
2
47
7MHB-4323-02A-W
Insulative PET sheet for T60 GPS antenna
1
48
7MHB-4323-01A-W
Conductive cloth of GPS antenna (for model T60)
1
49
8ATX-1R575G-WO
GPS antenna (for model T60)
1
50
8ATX-2R4G-WE
Wi-Fi + Bluetooth antenna
1
51
7MJS-4038-01A-W0
S760 spindle
1
52
7MHP-4253-03A-W0
Earphone cover (for model DP485)
1
53
7MHR-1727-09A-W3
Hand microphone case for R558 radio
1
54
7MHR-4253-01A-W3
Waterproof ring of earphone cover (for model DP485)
1
55
8ATX-4345-FJ-WA
4G diversity antenna (for model T60)
1
56
7GCB-070045005-J
Microphone cloth (for models DP770 and PT567)
1
57
7MHP-4237-01A-W0
DP485 front housing
1
58
7MHJ-4245-01A-W
Dual-sided adhesive for key PCB (for model DP580)
1
59
6SS1-4323-HKB
SMD nesting for key PCB (for model T60)
1
