Kirisun T60 Service Manual

SN
Material NO
Specifications
QTY
60
7MHS-4245-01A-W
Metal dome array of numeric keyboard (for model DP580)
1
61
7MHR-4245-02A-W0
Numeric keyboard (for model DP580)
1
6 Debugging
6.1 Preparation
Prepare the followings.
 Antenna interface converter
 Universal interface
 Test card
 General-purpose tester CWM500/8960
6.2 Index Verification
6.2.1 Frequency Bands
Model
T60/T65
Frequency
Band
B1 (2100MHz)
B2 (1900MHz)
B5 (850MHz)
B8 (900MHz)
Test ID
LOW
MID
HIGH
LOW
MID
HIGH
LOW
MID
HIGH
LOW
MID
HIGH
10562
10700
10838
9662
9794
9938
4357
4408
4458
2937
3013
3088
Model
T60/T65
Frequency
Band
B1
B3
B5
B8
Test ID
LOW
MID
HIGH
LOW
MID
HIGH
LOW
MID
HIGH
LOW
MID
HIGH
18050
18300
18550
19250
19575
19900
20450
20525
20600
21500
21625
21750
Model
T60/T65
