For installation/configuration, please observe the
Instruction Manual of the software. The Manual is avail-
able in the installation routine.
1.4 Interfaces
The unit is equipped with the following interface for connecting
additional units (hereafter referred to as “modules”) for monitoring
and documenting the temperature:
Tab. 4: Interfaces
Interface Module
LAN interface PRO-ACTIVE
n PC-KIT-NET (optional)
ULTIMATE
n PC-KIT-NET integrated
USB port PRO-ACTIVE
n PC-KIT-STICK
ULTIMATE
n Service interface
Potential-free alarm contact Remote warning system (for
example GSM-MODUL or con-
nection to building control
system (see circuit diagram on
unit))
For information about connecting the modules to the unit, see the
relevant product documentation.
Connect only compatible USB flash drives!
Connect only modules with the following properties to
the USB port:
– Maximum memory capacity of 32 GB
– Formatted in FAT-32 format
Remove USB flash drive after use!
The USB flash drive must not remain permanently in
the unit.
– Remove USB flash drive after the data transfer is
completed
Ä
‘Error messages and status displays
of the PC-KIT-STICK’ on page 69.
Product description
Interfaces
23.05.2023Refrigerator/freezer MED series14
