4-2
REMOVING THE COOKTOP GLASS
1. Unplug cooktop or disconnect power.
2. Remove the cooktop from its mounting
location, (see “Installation Instructions” in
Section 2). Position the cooktop so that
you can access the bracket screws below
the cooktop glass.
Electrical Shock Hazard
Disconnect power before servicing.
Replace all parts and panels before
operating.
Failure to do so can result in death or
electrical shock.
3. Remove the fourteen flat-head screws
from the front, rear, and side ceramic glass
brackets.
4. Remove the two small side brackets from
the cooktop base.
Front/Rear Bracket Screws
Side Bracket Screws
Small Side Bracket
Cooktop Glass
Cooktop Base
5. Lift and remove the ceramic glass from the
cooktop base.
Cooktop Glass
To Next Page
