KitchenAid KMTM704E Series User Manual

COMPONENT ACCESS
KitchenAid 2015 Microltration Dishwashers
n
4-9
4. Remove latch assembly from door, (see Figure 3).
5. Disconnect harness assembly.
Figure 3
Door Latch
Figure 4
Remove Latch Assembly
1. Unplug dishwasher or disconnect power.
2. Remove the outer panel from the door.
3. To remove latch assembly, insert a small at-blade
screwdriver into the clip slots on each side of the latch.
Gently push in to release latch clips, (see Figures 1 and 2).
Figure 1
Figure 2
Removing Latch Assembly
WARNING
Electrical Shock Hazard
Disconnect power before servicing.
Failure to do so can result in death or
electrical shock.
Replace all parts and panels before operating.
Strike
Entry
Front
