4-18
n
KitchenAid 2015 Microltration Dishwashers
COMPONENT ACCESS
Under Tub Components
Figure 1
Wash Motor
Heater
OWI / NTC
Drain Pump
Fill Valve
Diverter & Lower
Wash Arm Motor
Control Board
Blower Fan
Rotating
Inlet Filter
Motor
Capacitor
Terminal Box
Thermostat
Drain Hose
