COMPONENT ACCESS
KitchenAid 2015 Microltration Dishwashers
n
4-29
Removing Wash Motor & Rotating Inlet Filter
10. Remove RIF Filter Assembly - Li up and remove the lter
assembly from the motor assembly.
Figure 9
NOTE: The Rotang Inlet Filter is keyed to the motor assembly
for ease of reassembly.
11. Remove Impeller Assembly - Figure 10 shows the motor
and impeller assembly.
Figure 10
12. To remove the impeller; insert a screwdriver into the
motor housing vent to prevent the rotor from turning.
Firmly grasp the impeller with the other hand and remove
it from the motor sha. See Figure 11.
Figure 11
NOTE: The impeller service kit includes the impeller, staonary
seat face seal, and rotang seat face seal. See Figure 12.
Figure 12
Impeller
RIF “Rotating
Inlet Filter”
IMPELLER
STATIONARY SEAT
FACE SEAL
ROTATING SEAT
FACE SEAL
