KitchenAid W10216167A - Prepare Dishwasher

8
Option 1: Solid surface countertop installation
■ Install second set of mounting brackets 33½" (85 cm) from
floor. If needed, drill ¹⁄₈" pilot holes in cabinet.
Option 2: Wood countertop installation
■ Prepare dishwasher by folding over tabs located on the top
front as shown.
PREPARE DISHWASHER
1. Measure cabinet opening height from floor to bottom of
countertop.
2. Place corner packaging on the floor and place dishwasher on
its back.
3. Adjust leveling legs based on the cabinet opening
measurement and the chart below.
33¹⁄₂"
(85 cm)
E
L
A
Y
H
O
U
R
S
ST
A
R
T
S
T
A
T
4
8
Tip Over Hazard
Do not open dishwasher drawer until inside cabinet
opening.
Doing so can result in death or serious injury.
WARNING
WARNING
Excessive Weight Hazard
Use two or more people to move and install
dishwasher.
Failure to do so can result in back or other injury.
H
X
