— 36 —
Fig No. Part No. Part Name
Nos.
Per Hoist
Capacity
60kg 100kg 180kg 160kg 240kg
1 E2D1001 Top hook assembly 1
2 E2D1071T Hook latch assembly T 1
3 E2D1011 Top yoke complete set 1
4 E2D5091 Top pin assembly 2
5 E2D1021 Bottom hook complete set 1
6 E2D1071B Hook latch assembly B 1
7 E2D041 Chain pin 1
8 E2D049 Slotted nut 1
9 E2D096 Split pin 1
10 E3D101 Body 1
11 E2D117 Top pin E 1
12 E2D118 Shaft stopper 1
――――
13 E2D072 Socket bolt with spring washer 2
――――
14 E2D111 Oil plug 2
15 E2D112 Plug packing 2
16 E2D269 Pawl pin 1
17 E2D270 Pawl spring 1
18 E2D268 Pawl 1
19 E2D271 Snap ring 1
20 E2D114 Set pin 2
21 E3D401 Chain guide 1
22 E2D451 Socket bolt with spring washer 2
23 E3D421 Chain spring (option) 1
24 E3D1045 Stopper complete set 1
25 E3D046 Cushion rubber 2
26 E2D086 Socket bolt with spring washer 1
27 E2D087 Lever nut 1
28 E3D901 Gear oil 1
29
E2D1831 Chain container (3) 1
E2D1835 Chain container (6) 1
30 E2D854 Socket bolt BP 1
31 E2D853 U nut 1
32 E2D852 Split pin 1
33
E2D1051P Motor complete set for 120V, 50/60Hz 1
E2D1051D Motor complete set for 240V, 50/60Hz 1
34
E2D5508P Armature assembly for 120V, 50/60Hz 1
E2D5508D Armature assembly for 240V, 50/60Hz 1
35 E2D5507 Stator assembly 1
36 E2D509 Motor cover 1
37 E2D506 Motor flange 1
38 E2D1510 Lid assembly 2
39 E2D502 Carbon brush 2
40 E2D802 Name plate M
To Next Page
