KITO ED10ST - Page 45

— 43 —
Fig No. Part No. Part Name
Nos.
Per Hoist
Capacity
60kg 100kg 180kg 160kg 240kg
54 E2D651 Socket bolt with spring washer
3
――――
4
――――
61
E3DC1601 Control panel complete set 1
E3DC1601-C Control panel complete set *
1
1
62 E2D616L Converter assembly 1
63 E2D664A Fuse set *
64 E2D622 Silicone stack assembly 1
65 E2D667 Machine screw with spring washer 4 For converter
66 E2D663 Machine screw with spring washer 1 For silicone stack
67 E2D617L
Electromagnetic contactor 2
――――
Electromagnetic contactor complete set 1
――――
68
E2D661 Machine screw with spring washer 4 For contactor
――――
――――
Machine screw with spring washer 4
――――
For base
69 E2D619 Resistor 1
70 E2D665 Machine screw with spring washer 1 For resistor
71 E2D702L Transformer 1
72 E2D670L Nut 2 For transformer
73 E2D671L Machine screw with spring washer 2 For transformer
75 E3D371 Abrupt reverse operation protection board *
2
1
74 E2D651 Socket bolt with spring washer
3
――――
4
――――
Part which part No. is suffixed with L is only for low voltage control type hoist.
* Contents of fuse set are tabulated in page 33.
*1: Equipped with reverse-operation protection board.
*2: This part is only for AC240V type.
