KITO ED10ST - Page 48

— 46 —
Fig No. Part No. Part Name
Nos.
Per
Hoist
Supplement
14 E3D-583 Split pin 1
15 E3D-580 Joint yoke 1
16 E3D-592 Protection pad 2
17 E3D-593 Truss head machine screw 1
18 E3D-594 Washer 1
19 E3D-595 U nut 1
20 E1D-041 Chain pin 1
21 E1D-049 Slotted nut 1
22 E1D-096 Split pin 1
23 E3D-1480 Bottom hook complete set 1
24 E3D-2480 Bottom hook assembly 1
25 E3D-491 Hook latch assembly 1
26 E3D-2485 Bottom yoke assembly 1
27 E3D-485 Bottom yoke 2
28 E3D-496 Bolt 2
29 E3D-498 Spring lock washer 2
30 E3D-497 Nut 2
31 E3D-6489 Bottom shaft assembly 1
32 E3D-6487 Idle sheave assembly 1
33 E3D-482 Thrust collar A 1
34 E3D-483 Hook stopper 2
35 E3D-481 Thrust bearing 1
36 E3D-597 Name plate C 1
37 E3D-590 Chain spring 1
38 E3D-591 Washer 1
39 E3D-046 Cushion rubber 2
40 E3D-1045 Stopper complete set 1
41 E2D-086 Socket bolt with spring washer 1
42 E2D-087 Lever nut 1
43
E2D-1835 Chain container (6) 1 Lift: 3m
E2D-1833 Chain container (15) 1 Lift: 3.1-7.5m
E2D-1834 Chain container (30) 1 Lift: 7.6-15m
44 E2D-854 Socket bolt BP 1
45 E2D-853 U nut 1
46 E2D-852 Split pin 1
47 E2D-801 Name plate B 1
48 E2D-841 Load chain 1
49 E3D-599 Warning seal E (Finger protection) 1
