INSTALLATION
Install the lter
1 Water outlet tube of the lter hull 6 Water inlet tube of the lter hull
2 Fixed board of the lter hull 7 Filter core
3 Cover of lter hull 8 Washer
4 Washer of Connector 9 Filter hull
5 Connector of the lter hull
Insert lter
1 Set the washer into the groove of the upper lter hull.
2 Put the lter core into the lter hull, then cover both with the cover of the lter hull.
3 Fasten the xed board of the lter hull on the lter cover with screws.
4 Connect the lter hull connector with the water inlet tube of the lter hull, install the
washer, then connect it to the end of the lter cover with the inscription “in“ on it.
5 Connect the lter hull connector with the water outlet tube of the lter hull, install the
washer, then connect it to the end of the lter cover with the inscription “out“ on it.
6 After completing the installation, x the lter to the back of the ice maker with
screws.
7 Connect the water inlet tube of the lter hull to the water supply.
8 Connect the water outlet tube of the lter hull to the water inlet valve of the ice
maker.
