Klein Tools MM600 User Manual

Dwg Name: MM700-1390112ART
Dwg No: 1390112
ECO No: 20617 Rev: E
Pkg Dwg Ref: 1290186
Color Reference: N/A
8
FUNCTION BUTTONS
ON/OFF
To Power ON the meter rotate the Function Selector switch
2
from
the OFF setting to any measurement setting. To Power OFF the meter
rotate the Function Selector switch
2
to the OFF setting. By default
the meter will automatically Power OFF after 30 minutes of inactivity.
Reactivate meter by pressing any button. To deactivate the automatic
Power OFF feature, power the meter ON with the SEL button
11
depressed. When automatic Power OFF is deactivated, the
symbol will not be visible in the display.
When the Function Selector switch is rotated to a measurement
setting, "LEAD" flashes on the display as a reminder to check that test
leads are inserted into the appropriate jacks.
"SEL" (SELECT) BUTTON (FOR SECONDARY FUNCTIONS)
The "SEL" button
11
activates the secondary functions for each
setting accessible by the Function Selector switch
2
. For Current,
Voltage and Low Z, it toggles between AC and DC. For the other
functions, it switches between °F and °C, between Hz and %
Duty-cycle, and between Continuity, Resistance, and Diode-test.
The default function for each application is printed on the meter in
white; the secondary functions are printed on the meter in orange.
"HOLD" (DATA HOLD / BACKLIGHT) BUTTON
Press HOLD
10
to hold the measurement on the display. Press
again to release the display to return to live measuring.
Press and hold the "HOLD" button
10
for more than one second to
turn on or off the backlight. The backlight will automatically Power
OFF following three minutes of inactivity to conserve battery life.
"RANGE" BUTTON
The meter defaults to auto-ranging measurement mode
. This
automatically determines the most appropriate measurement range
for the testing that is being conducted. To manually force the meter
to measure in a different range, use the "RANGE" button
7
.
1. Press the "RANGE" button
7
to manually select measurement
range (
is deactivated on the LCD). Repeatedly press
the "RANGE" button
7
to cycle through the available ranges,
stopping once the desired range is reached.
2. To return to auto-ranging mode, press and hold the "RANGE"
button
7
for more than one second ( is reactivated).
ENGLISH
FUNCTION BUTTONS
"REL" (RELATIVE) BUTTON
Relative measurements are available for Voltage, Current,
Resistance, Temperature and Capacitance.
1. Perform first measurement.
2. With test leads connected, press REL
8
to set frame of reference.
3. Perform second measurement. The value displayed is the
difference between first and second measurements.
"MAX/MIN" BUTTON
When the "MAX/MIN" button
9
is pressed, the meter keeps track
of the minimum and maximum value of the measurement as the
meter continues to take samples.
1. When measuring, press MAX/MIN
9
and the meter displays the
maximum value. If a new maximum occurs, the display updates
with that new value. Pressing again reveals the minimum value.
If a new minimum occurs, the display updates with the new
value.
2. Press MAX/MIN
9
and hold for more than one second to return
to normal measuring mode.
MM700-1390112ART.indd 8 9/21/2015 2:44:48 PM

Klein Tools MM600 Specifications

General

Product type	Digital multimeter
Product color	Black, Orange
AC current range	0 - 10 A
DC voltage range	0 - 1000 V
Measuring category	CAT III 1000V, CAT IV 600V
Placement supported	Handheld multimeter
Temperature measurement range	-18 - 538 °C
International Protection (IP) code	IP42
Battery type	AAA
Power source	Battery
Number of batteries supported	2
Carrying case	Yes

Weight and Dimensions

Depth	178 mm
Width	90 mm
Height	53 mm
Weight	408 g
