SOFT 80, SOFT 100 PELLET-BURNING STOVE
EN - Rev. 1.0
Loosen the two screws shown in the picture (Figure 14) and dismantle the two RH and LH side panels (Figure 15).
Remove the cover of the cast iron top (Figure 17), by loosening the five screws shown in the picture (Figure 16).
14
15
16
17
1
2
