klover SOFT 80 - Page 45

40
SOFT 80, SOFT 100 PELLET-BURNING STOVE
EN - Rev. 1.0
Use a pipe cleaner or a vacuum cleaner to remove any dust residues from the cast iron heat exchanger (Figure 18).
Remove the cast iron heat exchanger (Figure 20), by loosening the 4 nuts shown in the picture (Figure 19).
18
19
20
