SOFT 80, SOFT 100 PELLET-BURNING STOVE
EN - Rev. 1.0
Use a steel scraper to scrape the side walls of the stove (Figure 21) and the inner walls of the cast iron heat exchanger
(Figure 22) then vacuum the residues.
Reassemble all the previously removed components, making sure that the seals guarantee perfect tightness.
When tightening the nuts of the cast iron heat exchanger, it is advisable to observe the sequence shown in the picture
(from 1 to 4) to ensure the adequate tightness of the seal (Figure 23).
21
22
23
1
4
3
2
