10.3 Aux Mix
To set the levels/balance of your selected auxiliary source, adjust the AUX MIX control as
follows:
AUX MIX control fully counter-clockwise / left
ENDGAME’s internal signal is 100% and the AUX signal is muted.
AUX MIX control at centre indent (12 o’clock position)
ENDGAME’s internal signal and the AUX signal are 50/50 equal.
AUX MIX control fully clockwise / right
The AUX signal is 100% and ENDGAME’s internal signal is muted.
Which outputs are active depends on ENDGAME’s Internal Dip Switch settings. For more
information, see
“Switch 1 – AUX BYPASS” in the
