42
12-ROW 40” STACK-FOLD RIPPER BEDDERS
(
68-12-40-R)
(Shown with Reset-on-the-Go Shanks)
20 40
114 3/4
120 13/16
190 3/8
196 1/2
241 1/2
116 1/2
40 40
248 104104
46
109 1/4
149 7/16
229 3/4
78 1/4
158 1/4
238 1/4
474 1/2 482 1/2
