48
Angle Adjustments
SINGLE DISC GANGS
Single Disc Assemblies (06-082-057) are use on
30” Row machine. Assemble Single Disc to the
disc mounting brackets (06-080-008) & (06-080-
081) and set angle.
DISC SCRAPER KIT
A Disc Scraper Kit (06-082-015) is made up of an 18” Disc Scraper and 20” Disc scraper which are
mounted to the disc mounting brackets. The 18” Disc Scraper requires a scraper support (06-023-049)
to mount the scraper to the disc mounting bracket as shown above.
Scraper Support
(06-023-049)
18” Disc Scraper
(06-027-004)
20” Disc Scraper
(06-023-050)
