54
RIPPER BEDDER STACKFOLD TRANSPORT DISTANCES:
Note: Use the “Overhead Layouts” portion of this section
for the transport width of Rigid Bar units.
MACHINE
SIZE
HEIGHT
TRANSPORT
HALF WIDTH (x2)
12/40
16/30
153” 154” X 2 = 308”
12(36-38) 152” 131” X 2 = 262”
12(30) 136” 111” X 2 = 222”
8(36-40) 140” 91” X 2 = 182”
"HALF WIDTH"
"HEIGHT"
