KMC Controls 68 Series

51
38” Row 40” Row
The 46” double bed doors can be setup using (46) DB Door Assembly (06-082-190)
The 48” double bed doors can be set up using (48) DB Door Assembly (06-082-184)
48” Row
End slot in shoe
thru this bolt.
End slot in shoe
thru this bolt.
46” Row
38”
(TYP)
40”
(TYP)
46”
(TYP)
48”
(TYP)
