1/2” x 5/8” Square Head
Cuppoint Setscrew.
°
For best performance the rear door needs to
be adjusted where doors are at approximately
45° to the ground. Adjust spring pressure to
add force or reduce firmness of bed tops
by loosening the 1/2” x 5/8” Square Head
Cuppoint Setscrew on top adjustable collar.
4
6
02-023-173
4 x 6 Bed Shaper
9
6
02-027-365
6 x 9 Bed Shaper
45.00°
Bed Shaper Plates Dimensions
