Key Management Systems Ltd 27 | P a g e
Maximum cable runs
Total KMS BUS 700 metres, includes BUS reader run.
Reader Interface Mk1 (designated by UDN 050) to reader 50 metres.
Reader Interface Mk2 (designated by UDN 052) to reader 100 metres.
Cat5, Cat5e or Cat6 network cable of known brand and
specification. 150ohm per 1000 metres minimum. Due to the
large variety of twisted pair data transmission cables
manufactured, KMS are unable to recommend or endorse any
brand.
Reader Interface to Reader
6 or 8 core Alarm multi-stranded cable, CW1308 (copper core)
Twin 1mm² copper flex assuming locks up to 1 Amp, installer
to calculate for larger loads / longer runs.
Alarm cable, CW1308, Cat5
Alarm cable, CW1308, Cat5
KMS provide Antennas in 5, 10, 15 and 20 metre lengths, all of
which must not be cut and re-terminated due to tuning of
antenna. Further information later in this guide.
