4.8 PTZ & RS-485 Setup
The DVR allows users to control PTZ functions of your camera. To enable PTZ function,
the 485 cable should be connected to the RS-485 port of DVR.
Item
Description
Enable PTZ
Click the box to Enable/Disable PTZ function for each channel.
Protocol
Set up the protocol of PTZ cam.
PTZ ID
Click or press ◀ ▶ to set up PTZ ID. The valid ID value is from 1 to 64.
Baud Rate
Select Baud Rate for PTZ from 2400、4800、9600 、19200
RS-485 ID
Reserved.
RS-485 Baud Rate
Keyboard
