6.3 Pneumatic connection
CAUTION
Personal injury or property damage
through ejected plugs
If not removed, the plugs on the outlet
of the pump can be ejected during op-
eration by the resulting overpressure.
àRemove the plugs during installa-
tion.
àWear appropriate personal protec-
tive equipment.
Connected com-
ponents
à
Only connect components to the pump that are designed
for the pneumatic data and thermal requirements of the
pump. (see Chapter 3 Technical data [}12]).
Pump discharge
à
Discharge the possibly hot pump discharge at the pneu-
matic outlet of the pump safely (with regard to medium
and noise).
Decoupling
à
KNF recommends mechanically decoupling the pump
from the pipe system, e.g., through the use of flexible
hoses or pipes. In this way it is possible to prevent the
transfer of possible pump vibrations and noises to the sys-
tem.
