40
Protos 3400(X)
SW 3400-103: Measurement Recorder
Select menu: Parameter setting/Module FRONT/Measurement recorder
Additional function SW 3400-103: Measurement recorder
The measurement recorder saves all entries in a file. The last 200 entries
can be displayed on the Protos. A new file is generated for each day.
The date is encoded in the file name.
Example for a file generated on SmartMedia card:
Recorder data of YYMMDD
(YY = year, MM = month, DD = day)
The data is recorded as ASCII file with the extension .TXT.
The individual columns are separated by tabs. This makes the file readable with
word processing or spreadsheet programs (e.g. Microsoft Excel).
Each time the memory card is inserted in the slot, a “Device Info” consisting of
Model number, BASE serial number and tag number is written.
Thus, a memory card can also be used to collect the measurement recorder
data of several devices.
Example:
