Knick Protos 34009(X) - SW 3400-006 Current Characteristic Definable

17
SW 3400-006: Current Characteristic Definable
Select menu: Parameter setting/Module BASE (OUT)/Output current/
Characteristic
Menu
Display
Specifying a current characteristic
Table characteristic
Assign output current to measured
value in 1-mA steps.
Select menu: Parameter setting/
Module BASE (OUT)/Output current
First select process variable!
Then select curve: Table
25.6 °C
7.03 pH
Variable
Start
End
Output
Output filter
Curve
Output current I1 (Administrator)
Trilinear
Function
Linear
Table
0000 s
pH
Abort
OK
+ 00.00 pH
+ 00.00 pH
+ 0000 pH
+ 0000 pH
+ 0000 pH
+ 0000 pH
OK
25.6 °C
7.03 pH
Variable
Output
Behavior during messages
Curve
Output filter
Output current I1 (Administrator)
Table
Table
0000 s
pH
Abort
OK
4 ... 20 mA
The “Table” menu is displayed.
The entered values must be
continuously rising or falling.
On the following page, you find a list-
ing to write down your adjustments.
Value at 01 mA:
Value at 03 mA:
Value at 04 mA:
Value at 02 mA:
Value at 05 mA:
Value at 00 mA:
Table (Administrator)
Abort
25.6 °C
7.03 pH
