Figure 39: Cyclone filter
1 Undo the wing nut (A) on the cover.
2 Remove the wing nut, the cover (B), and the filter housing (C) in that order.
3 Clean the filter housing with compressed-air or water.
If you clean the filter housing with water, ensure that the filter housing is
completely dry after cleaning.
4 Fit the filter housing, cover, and wing nut in that order.
5 Tighten the wing nut.
Maintaining the machine
65
