10.9 Lubricating the hinge points
10.9.1 Location of the lubrication nipples – standard version
Figure 42: Location of the lubrication nipples – standard version
C Lubrication nipple, center L Lubrication nipple, left
R Lubrication nipple, right
Maintaining the machine
68
