PARTS LIST
MODEL NO.:
CHX8130SQB
-
1 (30”)
CHX8130SQB-DC30-1 (30”)
CHX8136SQB-DC46-1 (30”)
CHX8136SQB
-
1 (36”)
CHX8136SQB-DC30-1 (36”)
CHX8136SQB-DC46-1 (36”)
NO.
DESCRIPTION
MODEL /SIZE
PART NO.
1
Duct Cover-Mounting Bracket
L1-0203-0092
2
Duct Cover RA092DC-1
12-00920-61
3
6” Round Plastic Exhaust
L1-0505-0003
4
LED Light Driver
L1-0402-D001
5
ON/OFF Switch
L1-0405-0101
6
Speed Switch (I/II)
L1-0405-0103
7
Speed Switch (Q)
L1-0405-0104
8
Light Switch
L1-0405-0102
9
LED Light (3W)
L1-0403-0301
10
Capacitor Support
L1-0201-0092
11
Blower System
L1-0302-0120-802RO
12
Capacitor x 1PCS
L1-0401-0120-24
13
Baffle Filter
L1-0214-0122
