3
COMPONENTS OF PACKAGE
(Must keep all material for returns or refunds)
Model No.:
CHX8130SQB-1 (30”)
CHX8130SQB-DC30-1 (30”)
CHX8136SQB-DC46-1 (30”)
CHX8136SQB-1 (36”)
CHX8136SQB-DC30-1 (36”)
CHX8136SQB-DC46-1 (36”)
{A} BRILLIA Range Hood (with RA092DC-1)
{B} Warranty Registration Card
{C} Quick Reference Guide
{D} Baffle Filter x 2 (30” hood)
x 3 (36” hood)
{E} Screws package
{F} 6” Round Plastic Collar
{G} Hood Mounting Bracket
{H} Duct Cover Mounting Bracket
{A}
{B} {C}
{D} {E}
{F} {G}
{H}
{I} Duct Cover Extension
Model No.: RA0930DC
{I}
{J} Duct Cover Extension
Model No.: RA0946DC
{J}
FOR MORE INFORMATION, PLEASE VISIT OUR WEBSITE www.koberangehoods.com OR
CONTACT KOBE RANGE HOODS AT (626) 775-8880.
Knob attached
to baffle filter
Pre-installed
Pre-installed
Duct Cover Box for RA0930DC
(Included in CHX81 SQB-DC30-1 ONLY)
Duct Cover Box for RA0946DC
(Included in CHX81 SQB-DC30-1 ONLY)
