OPERATING INSTRUCTIONS
This KOBE hood is equipped with four electronic controls with a 10-second standby startup & 30-
second delay shutoff, two powerful centrifugal turbine impellers with safety screens, two bright 12-volt
20-watt halogen lights, and four oil containers.
The four electronic controls are Light Control, Speed Control A (cycles through Low, Medium, High,
QuietMode™), Speed Control B (cycles through Low, QuietMode™, High, Medium) and the Power
Control (On/Off). Refer to Figure 32.
Figure 32
Turn On:
- Press Power Control (On/Off) button once. (If any Control button is not pressed within 10
seconds, power will be automatically turned off).
- The KOBE hood will start on Low speed. Each press of the Speed Control button will cycle
through the various speeds.
- Press Speed Control A button to cycle from Low, Medium, High, or QuietMode™. Press
Speed Control B button to cycle from Low, QuietMode™, High or Medium.
- Press Light Control button to turn halogen light on.
Turn Off:
- Press Power Control (On/Off) button once, panel lights will flash and power will be
completely shut off after 30 seconds.
OR
- Press Power Control (On/Off) button twice, all power will be shut off immediately.
- If only the lights are on, pressing Power Control (On/Off) button once will turn power off after
30 seconds.
Speed Control
A
(Cycles through Low, Medium, High,
QitMd
)
Power Control
Speed Control B
(Cycles through Low, QuietMode™, High,
Medium
)
Light
Control
