PARTS LIST
MODEL NO.: CH2230SQ
CH2236SQ
(Optional Duct Cover)
NO. DESCRIPTION MODEL /SIZE PART NO.
1 Multi Duct Exhaust C1-0507-0301
2 Vent Cover (Top) B101-1530-12
3 Vent Cover (Rear) C1-0508-0311-A
4 Vent Cover Screw (1/8” x 3/8”) C1-0708-0003
5 Vent Cover Frame C1-0508-0311-B
CH2230SQ 10-1630A 6 Hood Casing
CH2236SQ 10-1636A
7 Air Chamber C1-0101-1530
8 Motor (Right) C1-0301-0120-08A
9 Motor (Left) C1-0301-0120-07A
10 Turbine Impeller (Right) C1-0251-0880-02
11 Turbine Impeller (Left) C1-0251-0880-01
12 Oil Tunnel Seal C1-0502-0301
13 Oil Tunnel C1-0502-0203
CH2230SQ B101-1630-09 14 Bottom Casing
CH2236SQ B101-1636-09
15 Oil Container (Oval) C1-0504-0101
16 Safety Screen C1-0602-0101
17 Oil Container (Round) C1-0503-0101
18 Power Cord C1-0406-0120-01
19 Flat Head Screw (3/16” x 5/8”) C1-0704-0001
20 Wire Box C1-0231-0001
21 Round Head Screw (1/8” x 3/8”) C1-0708-0003
22 Round Head Screw (TS 4 x 6 mm) C1-0708-0001
23 Halogen Light (12V 20W Max.) C1-0403-0101
24 Transformer Support Screw (TS 4 x 6 mm) C1-0708-0001
25 Transformer Support C1-0201-1530
26 Transformer (Motor) C1-0402-A120-01
27 Control Unit C1-0501-0101
28 Control Board C1-0404-0401-A
29 Capacitor C1-0401-0120-01A
30 Processor Board Box C1-0501-0102
31 Processor Board C1-0404-0401-B
32 Round Head Screw (1/8” x 3/8”) C1-0708-0003
33 Transformer (Light) C1-0402-0120-40
34 Motor Position Screw (TS 1/4 x 7/16) C1-0703-0001
35 Round Head Screw (3/16” x 3/8”) C1-0707-0001
36 Bottom Casing Screw (3/16” x 5/8”) C1-0704-0001
37 Impeller Plastic Cover C1-0251-0001
38 Safety Screen Screw C1-0705-0001
NO. DESCRIPTION MODEL /SIZE PART NO.
39 Hood-Mounting Bracket C1-0221-1530
40 Screws (TS 4 x 8 mm) C1-0708-0006
41 Duct Cover CH1120DC 12-03000-0304
42 Duct Cover-Mounting Bracket C1-0203-0003
