ILLUSTRATED PARTS LIST
10 11DEC03 – IP5440-1
Figure 5 EXTRA BRIGHT LAMP MODULE AY
Item Part No. Description Quantity Notes
1 785130 SCREW
5 1
2 2B5832 PLATE AY - lamp and door
5 1 For the extra bright LAMP MODULE AY.
3 259556 SCREW
5 4
4 628104 LAMP - ANSI code, FHS
5 1 Listed in the Kodak Price Catalog.
5 259748 TERMINAL AY - lamp socket
5 1
6 628305 LENS - condenser
5 1
7 2B7754 MIRROR
5 1 For the EXTRA BRIGHT LAMP MODULE AY.
8 235849 EJECTOR - lamp
5 1
9 5B5625 DOOR - lamp module
5 1 For the EXTRA BRIGHT LAMP MODULE AY.
10 8B9864 LIGHT - door reading
5 1 For the EXTRA BRIGHT LAMP MODULE AY.
11 239313 SPRING - door latch
5 1 Not visible in graphic.
12 239314 LATCH - door
5 1
13 5B5831 MODULE AY - extra bright, lamp
5 1 Listed in the Kodak Price Catalog.
