Alphabetical Index
IP5440-1 – 11DEC03 45
Section 3: Alphabetical Index
Alphabetical Index
Part No. Description Figure No.
5B5148 ARM/LINK AY - solenoid plunger ay 16
250081 BAFFLE 7
221285 BAFFLE - upper light 7
221373 BEARING - cam shaft 15
221032 BEARING - lens support, all projectors 10
2J6630 BELT - fan drive 6, 7
221254 BELT - mechanism 13
254759 BLOWER AY - fan shaft 7
256801 BOARD AY - component, 4200, 4200-J, 4200-KK, 4400 projectors 6
256806 BOARD AY - component, 4200, 4200-J, 4200-KK, 4400 projectors 19
256807 BOARD AY - component, 4600, 4600-K, 4600-KK projectors 20, 6
256809 BOARD AY - component, 5600, 5600-J, 5600-KK projectors 21, 6
207279 BRACKET 8, 9
961758 BRACKET - focus motor 8
961760 BRACKET - focus motor, 4600 projector 9
4B0396 BRACKET - lens mount 9
5B5808 BRACKET - lens mount, 4200 and 4400 projectors 8
231787 BRACKET - lens support 8, 9
232127 BRACKET AY - auto-focus, 4600, 5600 projectors 16
231098 BUMPER - direction lever 13
196434 BUSHING 10
250566 BUSHING 13
228911 BUSHING - select lever 15
229364 BUTTON - elevation 2
178389 BUTTON - focus, EC2 17
173718 BUTTON - focus, EC3 17
3B0161 BUTTON - forward 1
3H7235 BUTTON - forward/reverse 17, 18
3B0162 BUTTON - reverse 1
223454 BUTTON - select 12
236908 BUTTON - top/select 12
--- CAPACITOR 6
443451 CAPACITOR - ceramic, 0.1 mF, ±10%, 100 V dc - 5600, 5600-KK, 5600-J,
medalist projectors
21
225783 CAPACITOR - electrolytic, 10 mF ±10%, 50 V dc 21
215887 CAPACITOR - electrolytic, 2.2 mF, +75%, -10%,50 V dc 21
215888 CAPACITOR - metalized, 0.1 mF, W±10%, 100 V dc 20, 21
243858 CAPACITOR - metalized, 0.22 mF, W±10%, 100 V dc 19, 20, 21
7C9441 CIRCUIT BOARD - photocell, all auto focus projectors 10
221394 CLAMP - 5600, 5600-J, 5600-KK projectors 10
254758 CLIP - retainer 7
170750 CONTACT AY - remote EC2, 4400 projector 17
184929 CONTACT AY - remote EC3 17
171055 CONTACT AY - remote, EC1 18
259460 CORD - power, 4200-J, 5600-J projectors 2
941962 CORD - power, 4200-KK, 4600-KK, 5600-KK projectors 2
