ILLUSTRATED PARTS LIST
46 11DEC03 – IP5440-1
7C3470 CORD - power, U.S. projectors 2
171054 CORD - remote 18
170749 CORD - remote, EC2 17
184927 CORD - remote, EC3, 5600-KK, 5600-J projectors 17
961759 COVER - focus motor 8, 9
7C3585 COVER - viewer screen, 5600 projector only 6
236078 COVER AY - blower 7
7C3457 COVER AY - cord wrap 2
251669 DAMPENER - foam, 4200-KK, 4600-KK, 5600-KK projectors 6
221478 DIODE - formed 17
5B5045 DOOR - lamp module 4
5B5625 DOOR - lamp module 5
5B5038 DOOR - storage 6
221018 DRAWER - viewer 3
5B4644 DRAWER AY - viewer, 5600, 5600-J, 5600-KK, medalist I projectors 3
221012 DRIVER - lens 11
236056 DUCT - pre-heat 7
128527 E-RING 13, 15, 16, 8, 9
129795 E-RING 2
213526 E-RING 16
235849 EJECTOR - lamp 4, 5
221252 ELEVATION AY 2
236070 FAN AY 7
219134 FILTER - photocell 10
226922 FOCUS AY - viewfinder 11
200687 FOLLOWER - drive lever 16
893402 FOOT 2
256812 FUSE - 2 AG, 1 AMP, slow-blow 19, 20, 21
145051 FUSE - 4200-KK, 4600-KK, 5600-KK projectors 6
691662 FUSE - main, 2.5 AMP, 250 V - 4200-KK, 4600-KK, 5600-KK projectors 7
226075 FUSE - thermal 7
784053 GATE - mechanical frame 14
5B5042 GRILLE AY - 4200, 4200-J. 4200-KK, 4400, 4600, 4600-KK projectors 6
5B5058 GRILLE AY - 5600, 5600-J projectors 6
5B5066 GRILLE AY - 5600-KK projector 6
215178 GROMMET 6
226844 GUIDE 11
5B5267 HOUSING - bottom remote 17, 18
251708 HOUSING - fuse, 4200-KK, 4600-KK, 5600-KK projectors 6
2E5901 HOUSING - lower, 4200, 4200-J, 4400, 4600 projectors 2
7C3453 HOUSING - lower, 4200-KK, 4600-KK projectors 2
2J6317 HOUSING - lower, 5600, 5600-J projectors 2
5B5064 HOUSING - lower, 5600-KK projector 2
221331 HOUSING - photocell 10
2J4084 HOUSING - top remote, EC1 18
5B5271 HOUSING - top remote, EC3, EC2 17
2E5900 HOUSING - top, 4200, 4200-J, 4400, 4600, 5600,5600-J projectors 12
5B5074 HOUSING - top, 4200-KK, 4600-KK, 5600-KK projectors 12
Alphabetical Index
Part No. Description Figure No.
