Kodak BC4401 - Carousel 4400 Projector - VIEWER FOCUS AY

Illustrated Parts List
IP5440-1 – 11DEC03 21
Figure 11 VIEWER FOCUS AY for the 5600, 5600-J, 5600-KK PROJECTORS
Figure 11 VIEWER FOCUS AY for the 5600, 5600-J, 5600-KK PROJECTORS
Item Part No. Description Quantity Notes
1 221319 RETAINER - viewfinder rack, 5600, 5600-KK,
5600-J, projectors
11
1
2 227181 SPRING - viewfinder lens
11 1
3 226844 GUIDE
11 1 Not included with the
VIEWFINDER FOCUS AY.
4 221068 SPRING
11 1
5 226922 FOCUS AY - viewfinder
11 1
6 226768 SPRING - viewfinder rack
11 3
7 221012 DRIVER - lens
11 1
A100_0021DA
7
5
4
3
2
1
A100_0021DCA
6
1
2
3
4
5
6
7
