ILLUSTRATED PARTS LIST
20 11DEC03 – IP5440-1
9 176252 SCREW 10 1
10 221392 PAD AY - clamp
10 1
11 221099 SPRING - photocell rack, all projectors
10 1
12 221022 RACK - photocell, all projectors
10 1
13 253789 SCREW - 5600, 5600-J, 5600-KK projectors
10 1
14 221394 CLAMP - 5600, 5600-J, 5600-KK projectors
10 1
15 221096 SPRING - clamp lever, 5600, 5600-J, 5600-KK projectors
10 1
16 166072 NUT - clamp lever, 5600, 5600-J, 5600-KK projectors
10 1
17 221377 LEVER - clamp, 5600, 5600-J, 5600-KK projectors
10 1
18 221032 BEARING - lens support, all projectors
10 1
19 5B5599 PAD - cork
10 1
20 221097 SPRING - photocell bracket
10 1
Item Part No. Description Quantity Notes
