Section 2: Numerical Index
Numerical Index
Part No. Description Figure No.
--- CAPACITOR 6
--- LAMP - ANSI code, FHS 4
--- REMOTE AY - complete 17
128527 E-RING 13, 15, 16, 8, 9
129795 E-RING 2
145051 FUSE - 4200-KK, 4600-KK, 5600-KK projectors 6
166072 NUT - clamp lever, 5600, 5600-J, 5600-KK projectors 10
166120 NUT 15
166985 SCREW 16
169836 SCREW 17, 18
170749 CORD - remote, EC2 17
170750 CONTACT AY - remote EC2, 4400 projector 17
171054 CORD - remote 18
171055 CONTACT AY - remote, EC1 18
173718 BUTTON - focus, EC3 17
176252 SCREW 10
178389 BUTTON - focus, EC2 17
184927 CORD - remote, EC3, 5600-KK, 5600-J projectors 17
184929 CONTACT AY - remote EC3 17
185636 LABEL - remote, EC3 17
188332 PIN - shutter 14
196434 BUSHING 10
200687 FOLLOWER - drive lever 16
205342 LABEL - serial number, U.S. projectors 2
207279 BRACKET 8, 9
207378 SPRING - shutter 14
213526 E-RING 16
215178 GROMMET 6
215242 SCREW 6
215887 CAPACITOR - electrolytic, 2.2 mF, +75%, -10%,50 V dc 21
215888 CAPACITOR - metalized, 0.1 mF, W±10%, 100 V dc 20, 21
217022 SWITCH - power 12
219134 FILTER - photocell 10
220040 RESISTOR - 68 k W, W±5%, 1/4 W 21
220044 RESISTOR - 1 k W, W±5%, 1/4 W 20, 21
220045 RESISTOR - 18 k W, W±5%, 1/4 W 21
220051 RESISTOR - 270 W, W±5%, 1/4 W 20, 21
220054 RESISTOR - 10 K W, 1/4 W, W±5% 21
220137 TRANSISTOR - 2N6027 - 5400 and 5600 projectors 21
221010 MASK - photocell 10
221012 DRIVER - lens 11
221014 SCREEN 3
221018 DRAWER - viewer 3
221022 RACK - photocell, all projectors 10
221032 BEARING - lens support, all projectors 10
221041 LEVER - auto focus 9
