ILLUSTRATED PARTS LIST
40 11DEC03 – IP5440-1
221051 SCREW - 5600, 5600-J, 5600-KK projectors 10
221053 SPRING 3
221054 SPRING 3
221065 SPRING 16
221068 SPRING 11
221075 MOTOR - U.S., all other standard projectors 6
221096 SPRING - clamp lever, 5600, 5600-J, 5600-KK projectors 10
221097 SPRING - photocell bracket 10, 9
221099 SPRING - photocell rack, all projectors 10
221106 SPRING - pressure pad 14
221133 SPRING - elevation 2
221160 KNOB - elevation 2
221173 SWITCH - auto focus, 5600-J, 5600-KK, medalist I projectors 9
221215 LEVER AY - indexer 13
221218 PULLEY AY - worm 13
221220 LEVER AY - drive 16
221223 PLATE - elevation 2
221227 LEVER AY - shutter 16
221237 SWITCH AY - select 14
221252 ELEVATION AY 2
221254 BELT - mechanism 13
221259 LOCATOR - locator lever ay 16
221285 BAFFLE - upper light 7
221319 RETAINER - viewfinder rack, 5600, 5600-KK, 5600-J, projectors 11
221331 HOUSING - photocell 10
221343 LEVER AY - locator cam 16
221362 SPRING - select lever 15
221373 BEARING - cam shaft 15
221374 RETAINER - worm pulley 13
221377 LEVER - clamp, 5600, 5600-J, 5600-KK projectors 10
221381 RECEPTACLE - lamp 7
221392 PAD AY - clamp 10
221394 CLAMP - 5600, 5600-J, 5600-KK projectors 10
221395 PLUNGER - rack solenoid, 5600, 5600-J, 5600-KK projectors 10
221419 TRACK - left 7
221478 DIODE - formed 17
221760 RESISTOR - 4.7 M W, W±5%, 1/4 W - 5400 and 5600 projectors 21
222102 SCR 20, 21
222355 SPRING 13
223454 BUTTON - select 12
223490 RESISTOR - 100 W, W±5%, 1/4 W 20, 21
223505 PAD - pressure, mechanical frame 14
223568 LEVER - select 15
224791 RESISTOR - 39 k W, W±5%, 1/4 W 20
225783 CAPACITOR - electrolytic, 10 mF ±10%, 50 V dc 21
225915 LEVER - spring indexer 16
225916 SPRING - shutter lever 16
226047 SPRING - solenoid 16
Numerical Index
Part No. Description Figure No.
