ILLUSTRATED PARTS LIST
38 11DEC03 – IP5440-1
J1 256819 SOCKET - 9-line 21 1
J2 256817 SOCKET - 7-line
21 1
Q1 273500 TRANSISTOR - NPN, EBC, PN100
21 1
Q2 222102 SCR
21 1
Q3 236751 SCR - 5600, 5600-J, 5600-KK projectors
21 1
Q4 220137 TRANSISTOR - 2N6027 - 5400 and 5600 projectors
21 1
R3 220045 RESISTOR - 18 k W, W±5%, 1/4 W
21 1
R4 220051 RESISTOR - 270 W, W±5%, 1/4 W
21 1
R5 223490 RESISTOR - 100 W, W±5%, 1/4 W
21 1
R6 220044 RESISTOR - 1 k W, W±5%, 1/4 W
21 1
R7 228939 RESISTOR - 82 W, W±5%, 2 W
21 1
R10 220051 RESISTOR - 270 W, W±5%, 1/4 W
21 1
R11 220045 RESISTOR - 18 k W, W±5%, 1/4 W
21 1
R12 220054 RESISTOR - 10 K W, 1/4 W, W±5%
21 1
R13 220054 RESISTOR - 10 K W, 1/4 W, W±5%
21 1
R14 221760 RESISTOR - 4.7 M W, W±5%, 1/4 W - 5400 and 5600
projectors
21
1
R15 220040 RESISTOR - 68 k W, W±5%, 1/4 W
21 1
R16 226597 RESISTOR - 47 W, 1/4 W, W±5%
21 1 Not visible in graphic.
R17 223490 RESISTOR - 100 W, W±5%, 1/4 W
21 1
Item Part No. Description Quantity Notes
