ILLUSTRATED PARTS LIST
44 11DEC03 – IP5440-1
6C1965 LIGHT - frame 14
784053 GATE - mechanical frame 14
784230 LEVER AY - slide lift 15
784239 PLATE AY - top 13
784335 SCREW - long repair 12
785004 LABEL - serial number, 4200-J, 5600-J projectors 2
785130 SCREW 13, 5
785136 SCREW - select switch 14
7C3453 HOUSING - lower, 4200-KK, 4600-KK projectors 2
7C3457 COVER AY - cord wrap 2
7C3470 CORD - power, U.S. projectors 2
7C3585 COVER - viewer screen, 5600 projector only 6
7C9441 CIRCUIT BOARD - photocell, all auto focus projectors 10
7C9783 MOTOR - 4200-J, 5600-J, standard projectors 6
7C9785 MOTOR - 4200-J, 5600-J, long life projectors 6
7C9786 MOTOR - U.S., all other long life projectors 6
893402 FOOT 2
8B9763 SCREW 14
8B9864 LIGHT - door reading 5
941962 CORD - power, 4200-KK, 4600-KK, 5600-KK projectors 2
941963 TRANSFORMER - 4200-KK, 4600-KK, 5600-KK projectors 6
941993 POWER INLET SOCKET - 4200-KK, 4600-KK, 5600-KK projectors 7
941999 LABEL - serial number, 4200-KK, 4600-KK, 5600-KK projectors 2
961672 SPRING - cam shaft 15
961757 MOTOR - focus 8
961757 MOTOR, focus 9
961758 BRACKET - focus motor 8
961759 COVER - focus motor 8, 9
961760 BRACKET - focus motor, 4600 projector 9
961848 SCREW 8, 9
988302 MOUNT AY - lens, 4200, 4200-J, 4200-KK projectors 12, 8
988303 MOUNT AY - lens, 4400 projector 8
988305 MOUNT AY - lens, 4600, 4600-KK projectors 12
989232 SYMBOL - corporate 6
989237 MODULE - voltage, 4200-KK, 4600-KK, 5600-KK projectors 6
Numerical Index
Part No. Description Figure No.
