Numerical Index
IP5440-1 – 11DEC03 43
3B0161 BUTTON - forward 1
3B0162 BUTTON - reverse 1
3H6864 LABEL - data, U.S. projectors 2
3H7235 BUTTON - forward/reverse 17, 18
443451 CAPACITOR - ceramic, 0.1 mF, ±10%, 100 V dc - 5600, 5600-KK, 5600-J,
medalist projectors
21
488303 MOUNT AY - lens, 4400 projectors 12
4B0396 BRACKET - lens mount 9
543384 SPACER 8, 9
5B4472 SPRING - retard 13, 14
5B4634 SPRING - worm pulley 13
5B4638 MODULE - transformer, complete, 4200-KK,4600-KK, 5600-KK projectors 6
5B4641 MIRROR - mount, 5600, 5600-J, 5600-KK projectors 3
5B4642 SCREEN - frame, 5600, 5600-J, 5600-KK projectors 3
5B4644 DRAWER AY - viewer, 5600, 5600-J, 5600-KK, medalist I projectors 3
5B5038 DOOR - storage 6
5B5042 GRILLE AY - 4200, 4200-J. 4200-KK, 4400, 4600, 4600-KK projectors 6
5B5045 DOOR - lamp module 4
5B5046 LIGHT - door reading 4
5B5047 PLATE AY - lamp and door 4
5B5058 GRILLE AY - 5600, 5600-J projectors 6
5B5064 HOUSING - lower, 5600-KK projector 2
5B5066 GRILLE AY - 5600-KK projector 6
5B5074 HOUSING - top, 4200-KK, 4600-KK, 5600-KK projectors 12
5B5146 SOLENOID AY - cycle 16
5B5148 ARM/LINK AY - solenoid plunger ay 16
5B5267 HOUSING - bottom remote 17, 18
5B5271 HOUSING - top remote, EC3, EC2 17
5B5599 PAD - cork 10
5B5621 LABEL - 4200-KK, 4600-KK, 5600-KK projectors 7
5B5625 DOOR - lamp module 5
5B5808 BRACKET - lens mount, 4200 and 4400 projectors 8
5B5830 SCREW 7
5B5831 MODULE AY - extra bright, lamp 4, 5
5B5894 MOTOR - pulley, U.S. projectors 6
628104 LAMP - ANSI code, FHS 5
628154 MIRROR - lamp module 4
628305 LENS - condenser 4, 5
628491 LENS - heat absorbing 4
628582 LENS - reading light 4
691662 FUSE - main, 2.5 AMP, 250 V - 4200-KK, 4600-KK, 5600-KK projectors 7
6C0907 PANEL - control, 4200 projector, long life only 1
6C0908 PANEL - control, 4400 projector, long life only 1
6C0909 PANEL - control, 4600 projector, long life only 1
6C0910 PANEL - control, 5600 projector, long life only 1
6C1825 SCREW 6, 8, 9
6C1937 SWITCH - auto focus, 4600, 5600, 4600-KK, 5600-J, 5600-KK projectors 14
6C1964 SHUTTER 14
