ILLUSTRATED PARTS LIST
42 11DEC03 – IP5440-1
236751 SCR - 5600, 5600-J, 5600-KK projectors 21
236908 BUTTON - top/select 12
239313 SPRING - door latch 5
239314 LATCH - door 5
239813 SPRING - door latch 4
239814 SWITCH AY - cycle, with power switch 12, 4
243858 CAPACITOR - metalized, 0.22 mF, W±10%, 100 V dc 19, 20, 21
250081 BAFFLE 7
250083 TRACK - right 7
250566 BUSHING 13
250634 SCREW 16
250739 KEY - spindle 12
251669 DAMPENER - foam, 4200-KK, 4600-KK, 5600-KK projectors 6
251699 INSULATOR - 4200-KK, 4600-KK, 5600-KK projectors 6
251708 HOUSING - fuse, 4200-KK, 4600-KK, 5600-KK projectors 6
253789 SCREW - 5600, 5600-J, 5600-KK projectors 10
254379 SCREW - hex, button 2
254442 SCREW - base 2
254443 SCREW - 4200-KK and 5600 projectors 7
254758 CLIP - retainer 7
254759 BLOWER AY - fan shaft 7
255936 TIMER AY - 5600, 5600-J, 5600-KK projectors 12
255944 MOUNT AY - lens, 5600, 5600-J, 5600-KK projectors 12
256801 BOARD AY - component, 4200, 4200-J, 4200-KK, 4400 projectors 6
256806 BOARD AY - component, 4200, 4200-J, 4200-KK, 4400 projectors 19
256807 BOARD AY - component, 4600, 4600-K, 4600-KK projectors 20, 6
256809 BOARD AY - component, 5600, 5600-J, 5600-KK projectors 21, 6
256812 FUSE - 2 AG, 1 AMP, slow-blow 19, 20, 21
256815 RECTIFIER - bridge, 1 AMP, 100 PIV, slow-blow 19, 20, 21
256817 SOCKET - 7-line 21
256819 SOCKET - 9-line 20, 21
257411 SHAFT AY - cam 15
259460 CORD - power, 4200-J, 5600-J projectors 2
259556 SCREW 4, 5
259735 MECHANISM AY - non-auto focus, 4200, 4400 projectors 12
259736 MECHANISM AY - auto focus, 4600, 5600 projectors 12
259748 TERMINAL AY - lamp socket 4, 5
273500 TRANSISTOR - NPN, EBC, PN100 20, 21
2B5163 RACK AY - solenoid, 5600, 5600-J, 5600-KK projectors 10
2B5832 PLATE AY - lamp and door 5
2B7754 MIRROR 5
2E5900 HOUSING - top, 4200, 4200-J, 4400, 4600, 5600,5600-J projectors 12
2E5901 HOUSING - lower, 4200, 4200-J, 4400, 4600 projectors 2
2J4084 HOUSING - top remote, EC1 18
2J6317 HOUSING - lower, 5600, 5600-J projectors 2
2J6630 BELT - fan drive 6, 7
3B0158 SLIDER - power/timer switch 1
3B0160 INTERFACE - power/timer 1
