ILLUSTRATED PARTS LIST
12 11DEC03 – IP5440-1
Figure 6 MOTOR and Electrical
Item Part No. Description Quantity Notes
1 215242 SCREW
6 1
2 215178 GROMMET
6 1
3 7C9783 MOTOR - 4200-J, 5600-J, standard projectors
6 1
7C9785 MOTOR - 4200-J, 5600-J, long life projectors
6 1
221075 MOTOR - U.S., all other standard projectors
6 1
7C9786 MOTOR - U.S., all other long life projectors
6 1
4 5B5894 MOTOR - pulley, U.S. projectors
6 1
5 2J6630 BELT - fan drive
6 1
6 232011 RECEPTACLE - remote
6 1
7 6C1825 SCREW
6 4
8 232994 WALL - stabilizer
6 1
9 251669 DAMPENER - foam, 4200-KK, 4600-KK, 5600-KK
projectors
6
1
10 256801 BOARD AY - component, 4200, 4200-J, 4200-KK, 4400
projectors
6
1
256807 BOARD AY - component, 4600, 4600-K, 4600-KK projectors
6 1
256809 BOARD AY - component, 5600, 5600-J, 5600-KK projectors
6 1
11 989237 MODULE - voltage, 4200-KK, 4600-KK, 5600-KK projectors
6 1
12 989232 SYMBOL - corporate
6 1
13 251708 HOUSING - fuse, 4200-KK, 4600-KK, 5600-KK projectors
6 1
14 145051 FUSE - 4200-KK, 4600-KK, 5600-KK projectors
6 1
15 5B5042 GRILLE AY - 4200, 4200-J. 4200-KK, 4400, 4600, 4600-KK
projectors
6
1
5B5058 GRILLE AY - 5600, 5600-J projectors
6 1
5B5066 GRILLE AY - 5600-KK projector
6 1
16 251699 INSULATOR - 4200-KK, 4600-KK, 5600-KK projectors
6 1
17 7C3585 COVER - viewer screen, 5600 projector only
6 1
18 5B5038 DOOR - storage
6 1
19 232954 LATCH - storage door
6 1
20 5B4638 MODULE - transformer, complete, 4200-KK,4600-KK, 5600-
KK projectors
6
1
21 941963 TRANSFORMER - 4200-KK, 4600-KK, 5600-KK projectors
6 1
22 227132 VARISTOR - motor, 4600, 5600 projectors
6 1 Not visible in
graphic.
23 --- CAPACITOR
6 1 Not visible in
graphic.
