ILLUSTRATED PARTS LIST
18 11DEC03 – IP5440-1
Figure 9 LENS MOUNT AY for the AUTO FOCUS PROJECTORS
Item Part No. Description Quantity Notes
1 231788 SPRING - focus shaft
9 1
2 226702 SPRING - lens mount
9 1
3 231787 BRACKET - lens support
9 1
4 231783 PAD - lens mount
9 1
5 207279 BRACKET
9 1
6 6C1825 SCREW
9 1
7 226084 RAIL - lens support
9 2
8 221173 SWITCH - auto focus, 5600-J, 5600-KK, medalist I
projectors
9
1
9 221041 LEVER - auto focus
9 1
10 128527 E-RING
9 1
11 543384 SPACER
9 1
12 961760 BRACKET - focus motor, 4600 projector
9 1
13 226061 SHAFT AY - worm
9 1
14 961848 SCREW
9 2
15 961759 COVER - focus motor
9 1
16 961757 MOTOR, focus
9 1
17 231792 SHAFT AY - focus
9 1
18 6C1825 SCREW
9 1
19 236625 MOUNT AY - lens, 4600, 4600-KK projectors
9 1
20 236076 MOUNT AY - lens, 5600, 5600-J, 5600-KK projectors
9 1
21 4B0396 BRACKET - lens mount
9 1
22 221097 SPRING - photocell bracket
9 1 Not visible in graphic.
