Illustrated Parts List
IP5440-1 – 11DEC03 23
Figure 12 MECHANISM AY and TOP HOUSING AY
Item Part No. Description Quantity Notes
1 236541 SCREW
12 8
784335 SCREW - long repair
12 1
2 217022 SWITCH - power
12 1
3 223454 BUTTON - select
12 1
4 259735 MECHANISM AY - non-auto focus, 4200, 4400 projectors
12 1
259736 MECHANISM AY - auto focus, 4600, 5600 projectors
12 1
5 250739 KEY - spindle
12 1
6 2E5900 HOUSING - top, 4200, 4200-J, 4400, 4600, 5600,5600-J
projectors
12
1
5B5074 HOUSING - top, 4200-KK, 4600-KK, 5600-KK projectors
12 1
7 488303 MOUNT AY - lens, 4400 projectors
12 1
988305 MOUNT AY - lens, 4600, 4600-KK projectors
12 1
255944 MOUNT AY - lens, 5600, 5600-J, 5600-KK projectors
12 1
988302 MOUNT AY - lens, 4200, 4200-J, 4200-KK projectors
12 1
11 239814 SWITCH AY - cycle, with power switch
12 1 Not visible in graphic.
12 236908 BUTTON - top/select
12 1 Not visible in graphic.
13 255936 TIMER AY - 5600, 5600-J, 5600-KK projectors
12 1 Not visible in graphic.
