Illustrated Parts List

IP5440-1 – 11DEC03 27

Figure 14 MECHANISM AY and SHUTTER AND GATE AY

Item Part No. Description Quantity Notes

1 6C1965 LIGHT - frame

14 1

2 221106 SPRING - pressure pad

14 1

3 188332 PIN - shutter

14 1

4 221237 SWITCH AY - select

14 1

5 785136 SCREW - select switch

14 1

6 232115 SPRING - coil

14 1

7 231702 LEVER - select switch

14 1

8 236541 SCREW

14 2

9 6C1964 SHUTTER

14 1

10 207378 SPRING - shutter

14 1

11 784053 GATE - mechanical frame

14 1

12 223505 PAD - pressure, mechanical frame

14 1

13 5B4472 SPRING - retard

14 1

14 6C1937 SWITCH - auto focus, 4600, 5600, 4600-KK, 5600-J, 5600-

KK projectors

15 8B9763 SCREW

14 1
